Four Colors Flexo Printing Machine Automatic Printing Length 177.8-355.6 Mm Voltage 380V±10%

Name: Four Colors Flexo Printing Machine Automatic Printing Length 17783556 Mm Voltage 380V10
Brand: SUNRISE
Price: 1 USD

China Four Colors Flexo Printing Machine Automatic Printing Length 177.8-355.6 Mm Voltage 380V±10% wholesale

Brand Name : SUNRISE

Model Number : SR-320-4

Certification : CE

Place of Origin : Zhejiang, China

MOQ : 1

Payment Terms : T/T

Supply Ability : 30 Set/Sets per Month

Delivery Time : within 30 days after deposit

Packaging Details : exported wooden case

Printing speed : 10-100 m/min

Printing color : 4 color

Max. web width : 320 mm

Max. printing width : 310 mm

Max. unwinding diameter : 600 mm

Printing length : 177.8-355.6 mm

Voltage : 380V±10%

Precision : ±0.15mm

Weight : 2200kg

Overall Dimensions(LxWxH) : 1800x 1100 x 2000mm

Contact Now

SR-320-4 Automatic Flexo Printing Machine

DETAILS FOR 4 COLORS FLEXO PRINTING MACHINE

ONE MOUNTING MACHINE
ONE ANILOX ROLLER FOR EACH GROUP
THREE SETS PRINTING ROLLER
PRINT BOTH SIDES(TURN BAR)
WITH LAMINATION
ONE UNWINDING TENSION CONTROLLER(MITSUBISHI JAPAN)
ONE REWINDING TENSION CONTROLLER
ONE DIE CUTTING STATION

Specifications:

l Adopt high quality ceramic anilox cylinder to transfer the ink.

l Unwinding is controlled by magnetic powder brake and rewinding is controlled by magnetic power clutch.

l Unwinding adopts auto tension controller.

l Each printing unit adopts 360° degree adjustment, it can independently gear and loosen, so other printing units can continue do printing.

l Each printing unit equips with IR and hot air

l Equipped with web guide for tracking.

l This machine with one die-cutting station, which makes printing and die-cutting can be finished in one process.

l The ink rollers will be separated from the printing rollers, and keep running when the machine stops.

l The main machine inverter is imported.

l It equipped with 3” air expanding shaft on unwinding/rewinding section.

l All the rollers are deal with thermal treated.

l The machine can finish material-feeding, printing, varnishing, drying, laminating, rewinding and die-cutting in a lump. It is an ideal machine for printing note and top-grade adhesive label.

Main Technical Parameters:
Printing speed	10-100 m/min
Printing color	4 color
Max. web width	320 mm
Max. printing width	310 mm
Max. unwinding diameter	600 mm
Max. rewinding diameter	600 mm
Printing length	177.8-355.6 mm
Voltage	380V±10%
Precision	±0.15mm
Voltage	three-phase four-wire 380V,50HZ
Weight	2200kg
Overall Dimensions(LxWxH)	1800x 1100 x 2000mm

Cylinder type automatic clutch
IR DRY UNIT
CAMERA INSEPECTPR (option)
EPC web guide
INVERTER
UNWINDING MAGNETIC BRAKE
ELECTRICAL CARBINIET
LAMINAINTING UNIT
UNWINDING TENSION (MITSUBISHI)
PLATE ROLLER, ANILOX ROLLER, OIL ROLLER
TURN BAR
UV DRIER (option)
Corona(OPTION)
ROTARY DIE CUTTER
